Configure High Availability Cluster in CentOS 7 (Step by Step Guide)

In my last article I had explained about the different kinds of clustering and their architecture. Before you start with the configuration of High Availability Cluster, you must be aware of the basic terminologies related to Clustering. In this article I will share step by step guide to configure high availability cluster in CentOS Linux 7 using 3 virtual machines. These virtual machines are running on my Oracle VirtualBox installed on my Linux Server.

Features of Highly Available Clusters?

The ClusterLabs stack, incorporating Corosync and Pacemaker defines an Open Source, High Availability cluster offering suitable for both small and large deployments.

• Detection and recovery of machine and application-level failures
• Supports practically any redundancy configuration
• Supports both quorate and resource-driven clusters
• Configurable strategies for dealing with quorum loss (when multiple machines fail)
• Supports application startup/shutdown ordering, regardless of which machine(s) the applications are on
• Supports applications that must/must-not run on the same machine
• Supports applications which need to be active on multiple machines
• Supports applications with multiple modes (eg. master/slave)

What Is Pacemaker?

We will use pacemaker and corosync to configure High Availability Cluster. Pacemaker is a cluster resource manager, that is, a logic responsible for a life-cycle of deployed software — indirectly perhaps even whole systems or their interconnections — under its control within a set of computers (a.k.a. nodes) and driven by prescribed rules.

It achieves maximum availability for your cluster services (a.k.a. resources) by detecting and recovering from node- and resource-level failures by making use of the messaging and membership capabilities provided by your preferred cluster infrastructure (either Corosync or Heartbeat), and possibly by utilizing other parts of the overall cluster stack.

Bring up Environment

First of all before we start toConfigure High Availability Cluster, let us bring up our virtual machines with CentOS 7. I am using Oracle VirtualBox. You can also install Oracle VirtualBox on Linux environment. Below are my vm’s configuration details

Edit the/etc/hostsfile and add the IP address, followed by an FQDN and a short cluster nodename for every available clusternode network interface.

[root@node1 ~]# cat /etc/hosts
127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4
::1 localhost localhost.localdomain localhost6 localhost6.localdomain6
10.0.2.20 node1.example.com node1
10.0.2.21 node2.example.com node2
10.0.2.22 node3.example.com node3

[root@node2 ~]# cat /etc/hosts
127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4
::1 localhost localhost.localdomain localhost6 localhost6.localdomain6
10.0.2.20 node1.example.com node1
10.0.2.21 node2.example.com node2
10.0.2.22 node3.example.com node3

[root@node3 ~]# cat /etc/hosts
127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4
::1 localhost localhost.localdomain localhost6 localhost6.localdomain6
10.0.2.20 node1.example.com node1
10.0.2.21 node2.example.com node2
10.0.2.22 node3.example.com node3

To finish, you must check and confirm connectivity among the cluster nodes. You can do this by simply releasing apingcommand to every cluster node.

Stop and disable Network Manager on all the nodes

[root@node1 ~]# systemctl disable NetworkManager
Removed symlink /etc/systemd/system/dbus-org.freedesktop.NetworkManager.service.
Removed symlink /etc/systemd/system/multi-user.target.wants/NetworkManager.service.

Configure NTP

To configure High Availability Cluster it is important that all your nodes in the cluster are connected and synced to a NTP server. Since my machines are in IST timezone I will use the India pool of NTP servers.

[root@node1 ~]# systemctl start ntpd
[root@node1 ~]# systemctl enable ntpd
Created symlink from /etc/systemd/system/multi-user.target.wants/ntpd.service to /usr/lib/systemd/system/ntpd.service.

Install pre-requisite rpms

The high availability package is not part of CentOS repo so you will need epel-release repo.

[root@node1 ~]# yum install epel-release -y

pcs is the pcaemaker software and all it’s dependencies The fence-agents-all will install all the default fencing agents which is available for Red Hat Cluster

[root@node1 ~]# yum install pcs fence-agents-all -y

Add firewall rules

[root@node1 ~]# firewall-cmd --permanent --add-service=high-availability; firewall-cmd --reload
success
success

ConfigureHigh Availability Cluster

The installed packages will create ahaclusteruser with a disabled password. While this is fine for runningpcs commands locally, the account needs a login password in order to perform such tasks as syncing thecorosync configuration, or starting and stopping the cluster on other nodes.

Set the password for the Pacemaker cluster on each cluster node using the following command. Here my password is password

[root@node1 ~]# echo password | passwd --stdin hacluster
Changing password for user hacluster.
passwd: all authentication tokens updated successfully.

Start the Pacemaker cluster manager on each node:

[root@node1 ~]# systemctl enable --now pcsd
Created symlink from /etc/systemd/system/multi-user.target.wants/pcsd.service to /usr/lib/systemd/system/pcsd.service.

Configure Corosync

To configure Openstack High Availability we need to configure corosync on any one of the node, usepcs cluster authto authenticate as thehaclusteruser:

[root@node1 ~]# pcs cluster auth node1.example.com node2.example.com node3.example.com
Username: hacluster
Password:
node2.example.com: Authorized
node1.example.com: Authorized
node3.example.com: Authorized

Finally, run the following commands on the first node to create the cluster and start it. Here our cluster name will bemycluster

[root@node1 ~]# pcs cluster setup --start --name mycluster node1.example.com node2.example.com node3.example.com
Destroying cluster on nodes: node1.example.com, node2.example.com, node3.example.com...
node3.example.com: Stopping Cluster (pacemaker)...
node2.example.com: Stopping Cluster (pacemaker)...
node1.example.com: Stopping Cluster (pacemaker)...
node1.example.com: Successfully destroyed cluster
node2.example.com: Successfully destroyed cluster
node3.example.com: Successfully destroyed cluster

Sending 'pacemaker_remote authkey' to 'node1.example.com', 'node2.example.com', 'node3.example.com'
node1.example.com: successful distribution of the file 'pacemaker_remote authkey'
node2.example.com: successful distribution of the file 'pacemaker_remote authkey'
node3.example.com: successful distribution of the file 'pacemaker_remote authkey'
Sending cluster config files to the nodes...
node1.example.com: Succeeded
node2.example.com: Succeeded
node3.example.com: Succeeded

Starting cluster on nodes: node1.example.com, node2.example.com, node3.example.com...
node2.example.com: Starting Cluster...
node1.example.com: Starting Cluster...
node3.example.com: Starting Cluster...

Synchronizing pcsd certificates on nodes node1.example.com, node2.example.com, node3.example.com...
node2.example.com: Success
node1.example.com: Success
node3.example.com: Success
Restarting pcsd on the nodes in order to reload the certificates...
node1.example.com: Success
node3.example.com: Success
node2.example.com: Success

Enable the cluster service i.e. pacemakerandcorosync so they can automatically start on boot

[root@node1 ~]# pcs cluster enable --all
node1.example.com: Cluster Enabled
node2.example.com: Cluster Enabled
node3.example.com: Cluster Enabled

Lastly check the cluster status

[root@node1 ~]# pcs cluster status
Cluster Status:
 Stack: corosync
 Current DC: node2.example.com (version 1.1.18-11.el7_5.3-2b07d5c5a9) - partition with quorum
 Last updated: Sat Oct 27 08:41:52 2018
 Last change: Sat Oct 27 08:41:18 2018 by hacluster via crmd on node2.example.com
 3 nodes configured
 0 resources configured

PCSD Status:
  node3.example.com: Online
  node1.example.com: Online
  node2.example.com: Online

To check the cluster’s Quorum status using the corosync-quorumtool command.

[root@node1 ~]# corosync-quorumtool
Quorum information
------------------
Date:             Sat Oct 27 08:43:22 2018
Quorum provider:  corosync_votequorum
Nodes:            3
Node ID:          1
Ring ID:          1/8
Quorate:          Yes

Votequorum information
----------------------
Expected votes:   3
Highest expected: 3
Total votes:      3
Quorum:           2
Flags:            Quorate

Membership information
----------------------
    Nodeid      Votes Name
         1          1 node1.example.com (local)
         2          1 node2.example.com
         3          1 node3.example.com

To get the LIVE status of the cluster use crm_mon

[root@node1 ~]# crm_mon
Connection to the CIB terminated

Verify the cluster configuration

Before we make any changes, it’s a good idea to check the validity of the configuration.

[root@node1 ~]#  crm_verify -L -V
   error: unpack_resources:     Resource start-up disabled since no STONITH resources have been defined
   error: unpack_resources:     Either configure some or disable STONITH with the stonith-enabled option
   error: unpack_resources:     NOTE: Clusters with shared data need STONITH to ensure data integrity
Errors found during check: config not valid

As you can see, the tool has found some errors.

In order to guarantee the safety of your data, [5] fencing (also calledSTONITH) is enabled by default. However, it also knows when no STONITH configuration has been supplied and reports this as a problem (since the cluster will not be able to make progress if a situation requiring node fencing arises).

We will disable this feature for now and configure it later. To disable STONITH, set thestonith-enabledcluster option to false on both the controller nodes:

[root@node1 ~]# pcs property set stonith-enabled=false

Next re-validate the cluster

[root@node1 ~]# crm_verify -L -V

This all about Configure High Availability Cluster on Linux, Below are some more articles on Cluster which you can use to understand about cluster architecture, resource group and resource constraints etc.

Lastly I hope the steps from this article to configure high availability cluster on Linux was helpful. So, let me know your suggestions and feedback using the comment section.
