OpenLDAP is a widely used open-source implementation of the Lightweight Directory Access Protocol (LDAP). It provides a centralized directory service for authentication, authorization, and identity management across Linux systems.
This tutorial demonstrates a tested, production-ready workflow to install and configure OpenLDAP on Rocky Linux 9 (RHEL 9 compatible) using the modern cn=config backend and ldapmodify commands.
If you are new to LDAP concepts, start here:
OpenLDAP Command Quick Reference (Rocky Linux 9)
| Task | Command | Purpose |
|---|---|---|
| Install OpenLDAP packages | dnf install openldap openldap-servers openldap-clients |
Installs LDAP server, client tools, and utilities |
| Enable and start slapd | systemctl enable slapd --now |
Starts OpenLDAP service at boot |
| Generate admin password | slappasswd |
Creates SSHA-hashed LDAP admin password |
| List configured databases | ldapsearch -Y EXTERNAL -H ldapi:/// -b cn=config dn |
Shows cn=config databases and backends |
| Modify LDAP configuration | ldapmodify -Y EXTERNAL -H ldapi:/// -f file.ldif |
Updates cn=config using LDIF |
| Load LDAP schemas | ldapadd -Y EXTERNAL -H ldapi:/// -f schema.ldif |
Adds required LDAP schemas |
| Add LDAP entries | ldapadd -x -D cn=admin,dc=example,dc=com -W -f file.ldif |
Creates users, groups, or base entries |
| Search LDAP directory | ldapsearch -x -b dc=example,dc=com |
Queries LDAP data |
| Modify LDAP entries | ldapmodify -x -D cn=admin,dc=example,dc=com -W -f file.ldif |
Updates existing users or groups |
| Delete LDAP entries | ldapdelete -x -D cn=admin,dc=example,dc=com -W dn |
Removes users or groups |
Lab Environment
NAME="Rocky Linux"
VERSION="9.4 (Blue Onyx)"
ID="rocky"
ID_LIKE="rhel centos fedora"
VERSION_ID="9.4"
SUPPORT_END="2032-05-31"
Single-node setup (LDAP server + client on same VM).
10.10.1.17 server.example.com server
Step 1: Update System Packages
sudo dnf update -y
Step 2: Install OpenLDAP Packages
Enable the Plus repository (required for openldap-servers on Rocky Linux 9 / RHEL 9):
sudo dnf config-manager --set-enabled plus
sudo dnf install -y openldap openldap-servers openldap-clients
Verify installed versions:
openldap-2.6.x
openldap-servers-2.6.x
openldap-clients-2.6.x
Step 3: Enable and Start slapd
Enable and start the OpenLDAP service (slapd):
sudo systemctl enable slapd --now
Verify that the service is running:
sudo systemctl status slapd
Step 4: Configure OpenLDAP (cn=config)
Rocky Linux 9 uses the dynamic cn=config backend, where all OpenLDAP
configuration is stored inside the LDAP database itself and managed using
ldapmodify. The legacy slapd.conf method is no longer used.
Generate Admin Password
Save the generated {SSHA} hash — this will be used to configure the LDAP
administrator (cn=admin) password.
slappasswd
Save the generated {SSHA} hash.
Identify Database Backend
sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=config dn
Rocky Linux 9 uses the MDB (Memory-Mapped Database) backend by default
(olcDatabase={2}mdb), which is recommended for performance and stability.
Configure Base DN and Admin DN
Create db.ldif:
dn: olcDatabase={2}mdb,cn=config
changetype: modify
replace: olcSuffix
olcSuffix: dc=example,dc=com
-
dn: olcDatabase={2}mdb,cn=config
changetype: modify
replace: olcRootDN
olcRootDN: cn=admin,dc=example,dc=com
-
dn: olcDatabase={2}mdb,cn=config
changetype: modify
replace: olcRootPW
olcRootPW: {SSHA}YOUR_HASH_HERE
Apply configuration:
sudo ldapmodify -Y EXTERNAL -H ldapi:/// -f db.ldif
Step 5: Load Required Schemas
These schemas are required for creating standard LDAP users, groups, and POSIX accounts on Rocky Linux 9.
sudo ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/cosine.ldif
sudo ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/nis.ldif
sudo ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/inetorgperson.ldif
Verify:
sudo ldapsearch -Q -LLL -Y EXTERNAL -H ldapi:/// -b cn=schema,cn=config dn
Step 6: Create Base DN and OUs
Base DN
The Base DN represents the root of your LDAP directory tree. All users and groups will be created under this namespace.
add-base.ldif
dn: dc=example,dc=com
objectClass: top
objectClass: dcObject
objectClass: organization
o: Example Organization
dc: example
sudo ldapadd -x -D cn=admin,dc=example,dc=com -W -f add-base.ldif
Organizational Units
Organizational Units (OUs) help logically separate users and groups inside the LDAP directory.
ou.ldif
dn: ou=people,dc=example,dc=com
objectClass: organizationalUnit
ou: people
-
dn: ou=groups,dc=example,dc=com
objectClass: organizationalUnit
ou: groups
sudo ldapadd -x -D cn=admin,dc=example,dc=com -W -f ou.ldif
Step 7: Manage Users and Groups
Add User
new_user.ldif
dn: uid=jdoe,ou=people,dc=example,dc=com
objectClass: inetOrgPerson
objectClass: posixAccount
objectClass: top
cn: John Doe
sn: Doe
uid: jdoe
uidNumber: 1001
gidNumber: 1001
homeDirectory: /home/jdoe
loginShell: /bin/bash
mail: jdoe@example.com
userPassword: {SSHA}USER_HASH
sudo ldapadd -x -D cn=admin,dc=example,dc=com -W -f new_user.ldif
Add Group
new_group.ldif
dn: cn=developers,ou=groups,dc=example,dc=com
objectClass: posixGroup
cn: developers
gidNumber: 1001
sudo ldapadd -x -D cn=admin,dc=example,dc=com -W -f new_group.ldif
Modify User
dn: uid=jdoe,ou=people,dc=example,dc=com
changetype: modify
replace: loginShell
loginShell: /bin/zsh
sudo ldapmodify -x -D cn=admin,dc=example,dc=com -W -f modify_user.ldif
Delete User or Group
sudo ldapdelete -x -D cn=admin,dc=example,dc=com -W uid=jdoe,ou=people,dc=example,dc=com
sudo ldapdelete -x -D cn=admin,dc=example,dc=com -W cn=developers,ou=groups,dc=example,dc=com
Frequently Asked Questions
1. Does Rocky Linux 9 use slapd.conf for OpenLDAP configuration?
No. Rocky Linux 9 uses the dynamic cn=config backend. All OpenLDAP configuration changes are performed using LDAP operations such as ldapmodify, not slapd.conf.2. Which database backend is used by OpenLDAP on Rocky Linux 9?
OpenLDAP on Rocky Linux 9 uses the MDB (Memory-Mapped Database) backend by default, which is recommended for performance and stability.3. Do I need the Plus repository to install OpenLDAP on Rocky Linux 9?
Yes. The openldap-servers package is provided through the Plus repository, which must be enabled before installation.4. Can this OpenLDAP setup be used on RHEL 9 or AlmaLinux 9?
Yes. The steps in this guide are fully compatible with RHEL 9 and AlmaLinux 9, as they share the same base architecture.5. Is this OpenLDAP setup suitable for production use?
Yes. This guide configures OpenLDAP using the supported cn=config backend and MDB database. For production environments, TLS (LDAPS) should also be configured.Conclusion
You have successfully installed and configured OpenLDAP on Rocky Linux 9 using the modern cn=config backend. This setup provides a clean, extensible foundation for centralized authentication and directory services in RHEL-based environments.
References
For more detailed instructions and further information, refer to
Official OpenLDAP Admin Guide
.
