Steps to configure NFS server & client in RHEL/CentOS 7/8

In this article we will cover:

• Comparison between NFSv2 vs NFSv3 vs NFSv4
• How to configure NFS server and client using NFSv4 in RHEL/CentOS 7/8 Linux
• How to configure NFS server and client using NFSv3 and NFSv2 in RHEL/CentOS 7/8 Linux
• Access NFS shares persistently and non-persistently in Linux

Network File System (NFS) is one of the native ways of sharing files and applications across the network in the Linux/UNIX world. NFS is somewhat similar to Microsoft Windows File Sharing, in that it allows you to attach to a remote file system (or disk) and work with it as if it were a local drive—a handy tool for sharing files and large storage space among users.

NFS2 vs NFS3 vs NFSv4

NFSv2

• Mount requests are granted on a per-host basis and not on a per-user basis.
• This version uses Transmission Control Protocol (TCP) or User Datagram Protocol (UDP) as its transport protocol.
• Version 2 clients have a file size limitation of less than 2GB that they can access.

NFSv3

• This version has more features than version 2, has performance gains over version 2, and can use either TCP or UDP as its transport protocol.
• Depending on the local file system limits of the NFS server itself, clients can access files larger than 2GB in size.
• Mount requests are also granted on a per-host basis and not on a per-user basis.

NFSv4

• This version of the protocol uses a stateful protocol such as TCP or Stream Control Transmission Protocol (SCTP) as its transport.
• The services of the RPC binding protocols (such as rpc.mountd, rpc.lockd, and rpc.statd) are no longer required in this version of NFS because their functionality has been built into the server
• NFSv4 combines these previously disparate NFS protocols into a single protocol specification.
• The portmap service is no longer necessary.
• It includes support for file access control list (ACL) attributes and can support both version 2 and version 3 clients.
• NFSv4 introduces the concept of the pseudo-file system, which allows NFSv4 clients to see and access the file systems exported on the NFSv4 server as a single file system.

Lab Environment

I have three Virtual Machines which I will use for NFS configuration of server and client. Below are the server specs of these Virtual Machines. These VMs are installed on Oracle VirtualBox running on a Linux server.

Install and Configure NFS Server (NFSv4) in RHEL/CentOS 7/8

• By default, the NFS server supports NFSv2, NFSv3, and NFSv4 connections in Red Hat /CentOS 7/8.
• However, you can also configure NFS server to support only NFS version 4.0 and later.
• This minimizes the number of open ports and running services on the system, because NFSv4 does not require the rpcbind service to listen on the network.
• When your NFS server is configured as NFSv4-only, clients attempting to mount shares using NFSv2 or NFSv3 fail with an error like the following:

Requested NFS version or transport protocol is not supported.

Install nfs-utils rpm

Install the nfs-utils package:

# yum install nfs-utils

NFS configuration using /etc/nfs/conf

Starting with RHEL/CentOS 7.7, to configure NFS server you must use /etc/nfs.conf instead of /etc/sysconfig/nfs. Since we plan to only enable NFSv4, we will disable older NFS versions using /etc/nfs.conf.

[root@centos-8 ~]# vim /etc/nfs.conf
[nfsd]
 vers2=n
 vers3=n
 vers4=y
 vers4.0=y
 vers4.1=y
 vers4.2=y

Optionally, disable listening for the RPCBIND, MOUNT, and NSM protocol calls, which are not necessary in the NFSv4-only case. Disable related services:

[root@centos-8 ~]# systemctl mask --now rpc-statd.service rpcbind.service rpcbind.socket
Created symlink /etc/systemd/system/rpc-statd.service → /dev/null.
Created symlink /etc/systemd/system/rpcbind.service → /dev/null.
Created symlink /etc/systemd/system/rpcbind.socket → /dev/null.

After you configure NFS server, restart the NFS server to activate the changes and enable it start automatically post reboot. You can also check nfs status using systemctl status nfs-server

[root@centos-8 ~]# systemctl restart nfs-server
[root@centos-8 ~]# systemctl enable nfs-server

Use the netstat utility to list services listening on the TCP and UDP protocols:

The following is an example netstat output on an NFSv4-only server; listening for RPCBIND, MOUNT, and NSM is also disabled. Here, nfs is the only listening NFS service:

[root@centos-8 ~]#  netstat --listening --tcp --udp | grep nfs
tcp        0      0 0.0.0.0:nfs             0.0.0.0:*               LISTEN
tcp6       0      0 [::]:nfs                [::]:*                  LISTEN

Create NFS share using /etc/exports

The /etc/exports file controls which file systems are exported to remote hosts and specifies options. It follows the following syntax rules:

• Blank lines are ignored.
• To add a comment, start a line with the hash mark (#).
• You can wrap long lines with a backslash (\).
• Each exported file system should be on its own individual line.
• Any lists of authorized hosts placed after an exported file system must be separated by space characters.
• Options for each of the hosts must be placed in parentheses directly after the host identifier, without any spaces separating the host and the first parenthesis.

Syntax:

export host1(options1) host2(options2) host3(options3)

In this structure:

• export: The directory being exported
• host: The host or network to which the export is being shared
• options: The options to be used for host

I have a folder /nfs_shares which we will share on our NFS server

[root@centos-8 ~]# mkdir /nfs_shares

In this NFS configuration guide, we create NFS share /nfs_shares to world (*) with rw and no_root_squash permission

[root@centos-8 ~]# cat /etc/exports
/nfs_shares     *(rw,no_root_squash)

The list of supported options which we can use in /etc/exports for NFS server

secure:         The port number from which the client requests a mount must be lower than 1024.
                This permission is on by default. To turn it off, specify insecure instead

ro:             Allows read-only access to the partition. This is the default permission whenever
                nothing is specified explicitly

rw:             Allows normal read/write access

noaccess:       The client will be denied access to all directories below /dir/to/mount.
                This allows you to export the directory /dir to the client and then to
                specify /dir/to as inaccessible without taking away access to something like /dir/from

root_squash:    This permission prevents remote root users from having superuser (root) privileges
                on remote NFS-mounted volumes. Here, squash literally means to squash the power of the remote root user

no_root_squash: This allows root user on the NFS client host to access the NFS-mounted directory with
                the same rights and privileges that the superuser would normally have.

all_squash:     Maps all User IDs (UIDs) and group IDs (GIDs) to the anonymous user. The opposite option
                is no_all_squash, which is the default setting.

Refresh NFS shares

Once you have an /etc/exports file setup, use the exportfs command to tell the NFS server processes to refresh NFS shares.

To export all file systems specified in the /etc/exports file:

[root@centos-8 ~]# exportfs -a

Use exportfs -r to refresh shares and reexport all directories (optional as we have already used exportfs -a)

[root@centos-8 ~]# exportfs -r

To view and list the available NFS shares use exportfs -v

[root@centos-8 ~]# exportfs -v
/nfs_shares     (sync,wdelay,hide,no_subtree_check,sec=sys,rw,secure,no_root_squash,no_all_squash)

Here,

-r:  Re-exports all entries in the /etc/exports file. This synchronizes /var/lib/nfs/xtab
     with the contents of /etc/exports file. For example it deletes entries from /var/lib/nfs/xtab
     that are no longer in /etc/exports and removes the stale entries from the kernel export table.

-a:  Exports all entries in the /etc/exports file. It can also be used to unexport the exported
     file systems when used along with the u option, for example exportfs -ua

-v:  Print the existing shares

-u:  Unexports the directory /dir/to/mount to the host clientA

For complete list of supported options with exportfs, follow man page of exportfs

Allow NFS server services with firewalld

We will add all the NFS services to our firewalld rule to allow NFS server client communication.

[root@centos-8 ~]# firewall-cmd --permanent --add-service mountd
success
[root@centos-8 ~]# firewall-cmd --permanent --add-service nfs
success
[root@centos-8 ~]# firewall-cmd --reload
success

Access NFSv4 shares on Linux Client

Access NFS shares temporarily (non-persistent)

• We will next use mount command to access NFS shares on Linux client.
• In this NFS configuration guide example, we have explicitly defined additional options -o argument to choose NFSv4 as the preferred option to mount the NFS share.
• Since we are using mount command, the changes will not be persistent across reboot.
• The /nfs_shares from nfs-server(centos-8) will be mounted on /mnt on the nfs-client.

[root@nfs-client ~]# mount -o nfsvers=4 10.10.10.12:/nfs_shares /mnt

If I try to access NFS shares using NFSv3, as you see after waiting for the timeout period the client fails to mount the NFS share as we have restricted the NFS server to only allow NFSv4 connections.

[root@nfs-client ~]# mount -o nfsvers=3 10.10.10.12:/nfs_shares /mnt
mount.nfs: No route to host

We can use mount command to list NFS mount points on nfs-client.

[root@nfs-client ~]# mount | grep nfs
10.10.10.12:/nfs_shares on /mnt type nfs4 (rw,relatime,vers=4.2,rsize=1048576,wsize=1048576,namlen=255,hard,proto=tcp,timeo=600,retrans=2,sec=sys,clientaddr=10.10.10.16,local_lock=none,addr=10.10.10.12)

To remove NFS share access you can unmount the mount point

[root@nfs-client ~]# umount /mnt

Allow permanent access to NFS shares (Persistent)

To access NFS shares persistently i.e. across reboots then you can add the mount point details to /etc/fstab. But be cautious before using this as it would mean that your NFS server is always accessible and it during boot stage of the NFS client, the NFS server is un-reachable then your client may fail to boot.

Add NFS mount point details in /etc/fstab in the below format. Here 10.10.10.12 is my NFS server. I have added some additional mount options rw and soft to access the NFS shares.

10.10.10.12:/nfs_shares /mnt            nfs     rw,soft         0 0

Next execute mount -a to mount all the partitions from /etc/fstab

[root@nfs-client ~]# mount -a

Check if the mount was successful and you can access NFS share on the client.

[root@nfs-client ~]# mount | grep /mnt
10.10.10.12:/nfs_shares on /mnt type nfs4 (rw,relatime,vers=4.2,rsize=1048576,wsize=1048576,namlen=255,soft,proto=tcp,timeo=600,retrans=2,sec=sys,clientaddr=10.10.10.16,local_lock=none,addr=10.10.10.12)

Install and Configure NFS Server (NFSv3) in RHEL/CentOS 7/8

NFSv2 and NFSv3 rely heavily on RPCs to handle communications between clients and servers. RPC services in Linux are managed by the portmap service.

The following list shows the various RPC processes that facilitate the NFS service under Linux:

rpc.statd

• This process is responsible for sending notifications to NFS clients whenever the NFS server is restarted without being gracefully shut down.
• It provides status information about the server torpc.lockdwhen queried.
• This is done via the Network Status Monitor (NSM) RPC protocol. It is an optional service that is started automatically by thenfslockservice.
• It is not required in NFSv4.

rpc.rquotad

• As its name suggests, rpc.rquotad supplies the interface between NFS and the quota manager.
• NFS users/clients will be held to the same quota restrictions that would apply to them if they were working on the local file system instead of via NFS.
• It is not required in NFSv4.

rpc.mountd

• When a request to mount a partition is made, the rpc.mountd daemon takes care of verifying that the client has the appropriate permission to make the request.
• This permission is stored in the /etc/exports file.
• It is automatically started by the NFS server init scripts.
• It is not required in NFSv4.

rpc.nfsd

• The main component to the NFS system, this is the NFS server/daemon.
• It works in conjunction with the Linux kernel either to load or unload the kernel module as necessary.
• It is, of course, still relevant in NFSv4.

rpc.lockd

• The rpc.statd daemon uses this daemon to handle lock recovery on crashed systems.
• It also allows NFS clients to lock files on the server.
• The nfslock service is no longer used in NFSv4.

rpc.idmapd

• This is the NFSv4 ID name-mapping daemon.
• It provides this functionality to the NFSv4 kernel client and server by translating user and group IDs to names, and vice versa.

rpc.svcgssd

• This is the server-side rpcsec_gss daemon.
• The rpcsec_gss protocol allows the use of the gss-api generic security API to provide advanced security in NFSv4.

rpc.gssd

• This provides the client-side transport mechanism for the authentication mechanism in NFSv4 and higher.

Install nfs-utils and rpcbind to setup NFSv3

We will install nfs-utils and additionally we will also need rpcbind to configure NFS server (NFSv3) in Red Hat/CentOS 7/8 Linux

[root@centos-7 ~]# yum -y install nfs-utils rpcbind

On Debian and Ubuntu you should install below list of rpms

# apt-get -y install nfs-common nfs-kernel-server rpcbind

Start nfs-server, rpcind services and check nfs status

We do not need any additional NFS configuration to configure NFS server (basic). But you can check /etc/sysconfig/nfs (if using RHEL/CentOS 7.6 and earlier) or /etc/nfs.conf (if using RHEL/CentOS 7.7 or higher) for any customization.

[root@centos-7 ~]# systemctl enable nfs-server --now
Created symlink from /etc/systemd/system/multi-user.target.wants/nfs-server.service to /usr/lib/systemd/system/nfs-server.service.

[root@centos-7 ~]# systemctl enable rpcbind

Check nfs status of nfs-server and rpcbind services to make sure the are active and running

[root@centos-7 ~]# systemctl status nfs-server
● nfs-server.service - NFS server and services
   Loaded: loaded (/usr/lib/systemd/system/nfs-server.service; enabled; vendor preset: disabled)
   Active: active (exited) since Sat 2020-04-18 17:03:24 IST; 8s ago
 Main PID: 1999 (code=exited, status=0/SUCCESS)
   CGroup: /system.slice/nfs-server.service

Apr 18 17:03:24 centos-7.example.com systemd[1]: Starting NFS server and services...
Apr 18 17:03:24 centos-7.example.com systemd[1]: Started NFS server and services.

[root@centos-7 ~]# systemctl status rpcbind
● rpcbind.service - RPC bind service
   Loaded: loaded (/usr/lib/systemd/system/rpcbind.service; enabled; vendor preset: enabled)
   Active: active (running) since Sat 2020-04-18 17:03:18 IST; 20s ago
 Main PID: 1982 (rpcbind)
   CGroup: /system.slice/rpcbind.service
           └─1982 /sbin/rpcbind -w

Apr 18 17:03:18 centos-7.example.com systemd[1]: Starting RPC bind service...
Apr 18 17:03:18 centos-7.example.com systemd[1]: Started RPC bind service.

Check the netstat output for listening TCP and UDP ports

[root@centos-7 ~]# netstat -ntulp | egrep nfs\|rpc
tcp        0      0 0.0.0.0:42725           0.0.0.0:*               LISTEN      1991/rpc.statd
tcp        0      0 0.0.0.0:20048           0.0.0.0:*               LISTEN      1995/rpc.mountd
tcp6       0      0 :::20048                :::*                    LISTEN      1995/rpc.mountd
tcp6       0      0 :::44816                :::*                    LISTEN      1991/rpc.statd
udp        0      0 0.0.0.0:880             0.0.0.0:*                           1982/rpcbind
udp        0      0 127.0.0.1:895           0.0.0.0:*                           1991/rpc.statd
udp        0      0 0.0.0.0:20048           0.0.0.0:*                           1995/rpc.mountd
udp        0      0 0.0.0.0:51945           0.0.0.0:*                           1991/rpc.statd
udp6       0      0 :::880                  :::*                                1982/rpcbind
udp6       0      0 :::20048                :::*                                1995/rpc.mountd
udp6       0      0 :::42581                :::*                                1991/rpc.statd

You can compare this output with NFSv4 setup, here we have more number of ports and service running with NFSv3 compared to NFSv4

Create NFS Shares

Next we will create a directory which we can share over NFS server. In this NFS configuration guide, I will create a new directory /nfs_shares to share for NFS clients.

[root@centos-7 ~]# mkdir /nfs_shares

The syntax and procedure to create NFS share is same between NFSv4 and NFSv3

Syntax:

export host1(options1) host2(options2) host3(options3)

In this structure:

• export: The directory being exported
• **host:**The host or network to which the export is being shared
• **options:**The options to be used for host

In this NFS configuration guide, we create NFS share /nfs_shares to world (*) with rw and no_root_squash permission

[root@centos-7 ~]# cat /etc/exports
/nfs_shares     *(rw,no_root_squash)

The list of options supported with NFSv3 configuration remains same as I shared under NFSV4 section of this article.

Refresh NFS shares

Once you configure NFS server and have an /etc/exportsfile setup, use theexportfscommand to tell the NFS server processes to refresh NFS shares.

To export all file systems specified in the /etc/exports file:

[root@centos-7 ~]# exportfs -a

List the currently exported NFS shares on the server. This command will also show the default permissions applied to the NFS share.

[root@centos-7 ~]# exportfs -v
/nfs_shares     (sync,wdelay,hide,no_subtree_check,sec=sys,rw,secure,no_root_squash,no_all_squash)

Allow NFS server services with firewalld

You can get the list of NFS and rpcbind ports used by NFSv3 from the netstat output we shared, instead we will use service list to allow firewall access for NFSV3

[root@centos-7 ~]# firewall-cmd --permanent --add-service nfs
success
[root@centos-7 ~]# firewall-cmd --permanent --add-service mountd
success
[root@centos-7 ~]# firewall-cmd --permanent --add-service rpc-bind
success

Reload the firewall service to make the changes persistent

[root@centos-8 ~]# firewall-cmd --reload
success

Access NFSv3 shares on Linux Client

Access NFS shares temporarily (non-persistent)

• We will next use mount command to access NFS shares on Linux client.
• These changes will not survive reboot and will be non-persistent.
• In this NFS configuration guide example, we have explicitly defined additional options -o argument to choose NFSv3 as the preferred option to mount the NFS share.

[root@nfs-client ~]# mount -o nfsvers=3 10.10.10.2:/nfs_shares /mnt

Check if the mount was successful

[root@nfs-client ~]# mount | grep /mnt
10.10.10.2:/nfs_shares on /mnt type nfs (rw,relatime,vers=3,rsize=524288,wsize=524288,namlen=255,hard,proto=tcp,timeo=600,retrans=2,sec=sys,mountaddr=10.10.10.2,mountvers=3,mountport=20048,mountproto=udp,local_lock=none,addr=10.10.10.2)

If I try to access NFS shares using NFSv4

[root@nfs-client ~]# mount -o nfsvers=4 10.10.10.2:/nfs_shares /mnt

As you see the client was allowed to access the NFS share even with NFSv4 so you see since we have not restricted our NFS server to only use NFSv3, it is allowing NFSv4 connections also.

[root@nfs-client ~]# mount | grep /mnt
10.10.10.2:/nfs_shares on /mnt type nfs4 (rw,relatime,vers=4.2,rsize=524288,wsize=524288,namlen=255,hard,proto=tcp,timeo=600,retrans=2,sec=sys,clientaddr=10.10.10.16,local_lock=none,addr=10.10.10.2)

You can use the same list of commands to list NFS mount points for NFSv3 mounts on the clients as I listed under NFSv4.

To remove NFS share access you can unmount the mount point

[root@nfs-client ~]# umount /mnt

Allow permanent access to NFS shares (Persistent)

To access NFS shares persistently i.e. across reboots then you can add the mount point details to /etc/fstab. But be cautious before using this as it would mean that your NFS server is always accessible and it during boot stage of the NFS client, the NFS server is un-reachable thenyour client may fail to boot.

Add NFS mount point details in /etc/fstab in the below format. Here 10.10.10.2 is my NFS server. I have added some additional mount options other than defaults, such as defaults, soft and nfsvers=3 to access the NFS shares only with v3 protocol.

10.10.10.2:/nfs_shares  /mnt    nfs     defaults,soft,nfsvers=3         0 0

Next execute mount -a to mount all the partitions from /etc/fstab

[root@nfs-client ~]# mount -a

Check if the mount was successful and you can access NFS share on the client.

[root@nfs-client ~]# mount | grep /mnt
10.10.10.2:/nfs_shares on /mnt type nfs (rw,relatime,vers=3,rsize=524288,wsize=524288,namlen=255,soft,proto=tcp,timeo=600,retrans=2,sec=sys,mountaddr=10.10.10.2,mountvers=3,mountport=20048,mountproto=udp,local_lock=none,addr=10.10.10.2)

Lastly I hope the steps from the article to install and configure NFS server and client using NFSv3 and NFSv4 on Red Hat and CentOS 7/8 Linux was helpful. So, let me know your suggestions and feedback using the comment section.

References:
Configure NFS Server with NFSv3 and NFSv4 in RHEL 8
NFS wiki page
Linux Administration: Network File System (NFS)

Related Searches: centos nfs server, how to setup nfs share, centos 7 install nfs server, how to check nfs status in linux, how to check if nfs server is running on linux, nfs in linux tutorial, nfs configuration in rhel 7 step by step, install and configure NFS server and client
